G4 8500GA

Range of application: Gaming
Microsoft® Windows® XP Professional
System based on: Shuttle XPC SN85G4V2
Chassis:
G4-type chassis made of Aluminum,
Color: black, mirror front face
dimensions: 30 x 20 x 18.5 cm (LWH)
Operating system/Software:
Microsoft Windows XP Professional
Ahead Nero 6, CyberLink PowerDVD 5, Adobe Reader 6.0
Processor: AMD Athlon 64 / 3200+, Socket 754, supports Hyper-Transport
Chipset: NVIDIA nForce3 150
Hard drive disk: ATA133, 200 GB (7200 UPM)
Optical drive: DVD writer 16x, Dual Layer support
Memory: 2x 512MB = 1024MB, DDR SDRAM
Graphics card: NVIDIA FX5900XT (128 MB), AGP 8X
Audio: 6-channel audio controller with SPDIF in/out
Card-Reader: integrated 6-in-1 USB 2.0 Card Reader
Free expansion slots: 1x PCI
Front-panel I/O
Microphone
Headphone (Line-out)
Line-in
2x USB 2.0
Firewire (IEEE 1394, 4 pol.)
Back-panel I/O
VGA (1x Sub-D, 1x DVI)
TV out
Firewire (IEEE 1394, 6 pin)
PS/2 for mouse and keyboard
LAN (RJ45, 100 MBit/s)
2x USB 2.0
6-ch Audio
SPDIF: optical in/out
Line-in
Serial port (COM)
Parallel port
optional Wireless LAN module
Power supply: Silent-X 240W (100~240V, PFC)
Weight: net: 5,1 kg, gross 6,5 kg
Warranty: 2 years on-site-service
Conformity
This device is classed as a technical information
equipment (ITE) in class B and is intended for use in
living room and office. The CE-mark approves the
conformity by the EU-guidelines:
- EMV-guideline 89/336/EWG electromagnetic tolerance
- LVD-guideline 73/23/EWG use of electric devices
within certain voltage-limits
