Spectacular

1. Spectacular, bandwidth-rich computing

The XPC SN85G4v3 destroys the myth that bigger PCs are faster. Designed for power-hungry users, this AMD Athlon 64-based small form factor (SFF) computer delivers tower-crushing, performance in one-third the space. Do everything faster, get the XPC SN85G4v3 today!

64-bit enabled core

Enter the 64-bit computing epoch with this bleeding-edge NVIDIA nForce™3 250 and AMD Athlon 64-based small form factor (SFF) computer. Configured to run Microsoft® Windows® XP 64-bit version, the SN85G4 delivers scalable platform and longevity second to none.

Awesome memory-awesome power

Drive new performance into your digital workflow or game play with support for high-bandwidth AMD Athlon 64 processors, DDR400 memory and wicked-fast Serial ATA RAID. With HyperTransport-enhanced performance and robust overclocking features, you can push the XPC SN85G4v3 to the limit.

Advanced I/O

Beautifully integrated 8-in-1 card reader delivers exceptional storage and connectivity flexibility. With FireWire® 400, USB 2.0 and SPDIF digital audio I/O built-in, it’s easy to connect all of your peripherals. Further, with 10/100 LAN built-in and optional 802.11g WLAN, the XPC SN85G4 offers a full palate of options to share your digital files — audio, video and pictures.

Excellent ergonomics

Shuttle’s proprietary Silent X technology makes the XPC SN85G4 v3 cool and quiet. Advanced Integrated Cooling Engine technology, intelligently-engineered airflow mechanics, Silent X 240W PSU and the classic good looks of Shuttle’s G2-series enclosure make the XPC SN85G4 v3 an optimal desktop replacement.

2. Silent X Technology

XPC SN85G4 v3 has been enhanced with the latest Silent X technologies. The Silent X concept is embodied in a number of discreet Shuttle technologies, including: A 240W Silent X PSU, Integrated Cooling Engine (ICE) and Intelligently-engineered airflow mechanics.

Integrated Cooling Engine (ICE) Module

The Integrated Cooling Engine (ICE) included in the XPC has been purpose designed for whisper quiet operation. The ICE heat-pipe module uses convection cooling to transfer heat away from the processor. Copper tubing, coated in nickel and filled with distilled water provides the conduit through which heat passes to a radiator. A quiet, speed controlled 92mm ducted fan covers the radiator, providing both processor cooling and case exhaust. Every XPC uses this patented cooling technology to prevent heat damage and deliver some of the quietest computers available.

Smart Fan

Included Smart Fan features intelligently monitor and control system cooling fans. Smart Fan incorporates linear control metrics to provide optimal cooling. Under normal conditions, Smart Fan keeps the fan speed low, minimizing acoustic noise. When the load increases, Smart Fan increases the fan speed to provide optimal cooling. Better still, Shuttle’s Smart Fan lets you choose the desired temperature and fan speed to suite your ergonomic needs.

240 Watt Power Supply

The SN85G4 v3 features the “Super Quiet, Super Cool” Silent X 250W PSU. Tested in our acoustic lab from a distance of 50cm (many competitors take measurements at 1M), this Shuttle Silent X 250W PSU produces 32dB (or less) noise.

Intelligently Engineered Airflow

The XPC SN85G4 v3 features more air intake points designed to keep the motherboard cool and stable. The chassis and underside of this XPC feature strategically positioned intake points that channel cool air across critical components. These intake points are engineered—size and position—to minimize noise.

3. G4 Chassis

The G4 chassis uses our high-grade RefleXion material for the sleekness of a mirrored face without the obnoxious flat glare of 1980s bedroom decor. We have even added a subtle dash of holographic color accenting our logo.

Easy Installation

So easy, even a first time user can put a powerful XPC together in less than 20 minutes - From scratch. Removable HDD cages simplify installation, and pre-routed and clearly labeled cables make installing components an absolute breeze. You’ll be amazed how easy it is!

Incredible expandability

At only 18 x 20 x 30cm or one-fifth the size of a tower PC, the G4-chassis features amazing expandability. For instance, load this machine 120GB of storage, 1GB of DDR400 and a versatile dual format DVD Rewriter (black) such as the CR40, and you have a system that leaves a Tower PC wanting.

4. Technical Specs

Processor	AMD Socket 754 Athlon™ 64 / Sempron™
Memory	DDR 400/333/266 (2) DIMM slots (2GB max)
Motherboard	FN85 (proprietary) NVIDIA nForce™3 250 Northbridge 1600MHz system bus with HyperTransport™ link (1) 32-bit PCI slot
Graphics	8X AGP slot
Audio	6-channel audio Digital (SPDIF) audio ports Analog audio ports
Network	10/100 LAN
8-in-1 Memory Card Reader	CF I/II, MS, MSP, SD, MMC, SM, MD
Storage	(2) ATA133 headers (2) Serial ATA 150 w/ RAID (0, 1, JBOD) headers (1) FDD header (1) 5.25” storage bay(1) 3.5” storage bay
Front-panel I/O	8-in-1 card reader (2) USB 2.0 ports FireWire® mini port Microphone port Headphone port Line-in port Power button Reset button
Rear-panel I/O	PS/2 Keyboard socket PS/2 Mouse socket (2) USB 2.0 ports FireWire® 400 port 10/100 LAN (RJ45) 6-channel audio out SPDIF I/O ports Coaxial-out Serial port Parallel port (Optional) Clear CMOS
Silent X (system cooling)	Integrated Cooling Engine (ICE) Intelligently-engineered airflow mechanics
Power Supply	240W
Dimensions (L x W x H, mm)	300 x 200 x 185
Weight (net / gross; kg, lbs)	2.85 (6.27) / 4.65 (10.23)
